Hydrokinetic Energy Current Turbine
The Hydrokinetic Energy Current Turbine consists of a permanent magnet alternator with a unique Venturi/Bernoulli flow acceleration system that does not involve a shaft or gears and requires very low maintenance. Potential environmental impacts are mitigated by incorporating a combination of design including elements including: a large wildlife and debris excluder, an easy way out for small marine life, EMF shielding, and non-toxic coatings. This turbine design can be installed on floating structures, or can be piling-mounted and pivoting with a very small footprint on the ocean floor/substrate, or can be mounted on a hoist attached to a bridge or seawall, or can be towed behind a vessel. The design can accommodate sizing and output capabilities for site specific requirements from small (1.5 kW) to large scale (up tp 6 MW) installations. A turbine can be grid-connected or off-grid linked to a storage and inverter system.
Additional Information
Device Status
Is the device actively being developed or is available for purchase (active)? Or has development or support ended (inactive)?
Active
Technology Type
Power Take-Off
Mechanism that converts the motion of the prime mover into a useful form of energy such as electricity, learn more
Direct Drive Generator
Surface ExpressionTrue
Estimated TRL
Estimated Technology Readiness Level scale from 1 to 9 with 9 being the most mature technology
TRL Last updated: 5 October 2022
4
Energy Resource
- Tidal
Water Column Position
Surface
--------------------------------------------
Submerged - Mid
Entire Water Column
--------------------------------------------
Submerged - Bottom
Last Modified
22 August 2024
